Roto molding requires the use of ReleaSys RM Rotational molding release agent

Rotational Molding Release Agent | ReleaSys™ RM

ReleaSys RM is heat stable to >600°F, cures rapidly (even at room temperature), and transfers no mold release to the part. With ReleaSys RM, customers achieve multiple releases, no transfer, reduced pigment build-up, lower scrap rates, better cosmetics, increased productivity, and the safety of a water-based system.

  • Multiple Releases per Application
  • Rapid Cure; No Transfer
  • Heat Stable up to 600°F
  • Optimized Resin Flow Out
CLICK HERE TO SEND INQUIRY OR REQUEST A QUOTE
Categories: , , Tags: , , ,
CLICK HERE TO CHAT WITH AN EXPERT ABOUT THIS PRODUCT

Rotational Molding Release Agent | ReleaSys™ RM

Design for the Toughest Rotational Molding Applications; Exceptional Longevity, Ease of Release, and Surface Quality

Miller-Stephenson’s ReleaSys™ RM Rotational molding release agent combines over 50 years of release agent expertise and rotational molding experience. Rotational Molding is a dynamic industry which utilizes a variety of  thermoplastic resins. In response to this evolution, Miller-Stephenson has developed the ReleaSys™ RM. The RM release coating is tailored to meet rotational molding efficiency challenges such as shorter, hotter cycles, tighter tolerances, and complex molds. ReleaSys RM is heat stable to 700°F, cures rapidly (even at room temperature), and transfers no mold release to the part.  These exceptional performance characteristics are to a proprietary formulation which tenaciously binds to the mold surface, providing a high release, abrasion resistance coating. The low surface energy of the coating, enhances flow of the melting resin, minimizing surface defects and decreasing cycle times.

Benefits of ReleaSys™ RM Rotational Molding Release Agent

  • Multiple releases from a single application
  • High Temperature Stability ( >600° F)
  • No Transfer or Pre-Release Issues
  • Lower Scrap and Improved Release Ease
  • Reduced Pigment Build up; Better Cosmetics
  • Enhanced Resin Flow Out
  • Increased Productivity through reduced downtime
  • No VOC, No Odor; Water based formulation

Applications of ReleaSys RM Rotational Molding Release Agent

ReleaSys™ RM rotational molding release products should be applied via any method which delivery fine atomization or via a microfiber cloth.  Ideally the mold surface would be between 20°C (68°F) and 205°C (400°F). Spray application is recommended, although brushing or wiping may also be used. Optimum multiple release performance is obtained by applying to molds preheated above 60°C (140°F). The ease of release, number of releases/application and surface finish will depend on application technique, mold temperature and number of coats applied. ReleaSys RM has been optimized for use on the following plastics:

  • LLDPE, LDPE, MDPE, HDPE, XLPE,
  • Polypropylene (PP)
  • Nylon / Polyamide
  • Polycarbonate
  • Fluoropolymer Resin

Miller-Stephenson can customize a ROTOMOLDING release agent for your specific needs

Miller-Stephenson prides itself on having a robust and dynamic R&D facility which can efficiently and quickly develop a customize formula for your specific rotational molding operation. We typically find this is necessary if a mold has particularly challenging undercuts, scuppers, bolts, pins or drafts. Our team will find an immediate solution to your unique challenges and delivery a rotational molding release agent to meet not only your performance requirements, but your cost requirements as well.

ReleaSys™ RM – Designed for to work where other release coating fail

Producing a high quality, dimensionally controlled rotomolded part would be easy if all parts were the same shape and size, but they are not. For example, a fuel cell for a marine application usually needs to be molded in a shape that will allow it to fit into a very irregular and tight space envelope. A Silo style storage tank, on the other hand, is a large and regular in shape. The demands placed on the release agent for these two applications are very different. The marine gas tank will usually require a release agent that provides excellent resin flow & maximum release assistance.  The large water tank requires similar flow assistance but a modified slip level to prevent pre-release. Thanks to Miller-Stephenson’s extensive expertise in the rotomolding industry we understand the problems rotomolders experience and have developed specialized rotational molding release agents to meet these specific requirements.

For help with application or troubleshooting concerns while using ReleaSys.

If you would like more information on which mold release agent is right for you click here

For further reading regarding our ReleaSys product line and Applications – our most helpful article for selecting the best product for your needs

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

Physical Properties:

Primary PolymerCrosslinking Polysiloxane
AppearanceWhite Emulsion
OdorNone
Specific Gravity1.0 g/mL
Flash PointNone

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

ReleaSys RM rotational mold release products should be applied via any method which can deliver fine atomization or via a microfiber cloth. Ideally the mold surface would be between 20°C (68°F) and 205°C (400°F). Spray application is recommended, although brushing or wiping may also be used. Optimum multiple release performance is obtained by applying to molds preheated above 60°C (140°F). The ease of release, number of releases/application and surface finish will depend on application technique, mold temperature and number of coats applied.

  • LLDPE, LDPE, MDPE, HDPE, XLPE,
  • Polypropylene (PP)
  • Nylon / Polyamide
  • Polycarbonate.

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

1 gallon, 5 gallon, 55 gallon, 275 tote
