ReleaSys HTX-WBN is superior boron nitride coating offer excellent performance for metal, plastic, and glass molding

Boron Nitride Coatings | ReleaSys™ HTX-WBN

ReleaSys™ HT is a specialized, water-based release agent specifically designed for high temperature molding operations.  This formula utilizes a proprietary boron nitride complex to achieve unmatched lubricity and mold release performance. The inert and non-wetting nature of ReleaSys™ HT makes it an excellent surface coating for molds used to produce castings of light metals such as magnesium and for coating surfaces in glass making operations. Advantages include:

  • Water-based; VOC-free formula
  • Enhanced surface adhesion and durability
  • Protects Mold and Die Surfaces
  • High Temperature Stability up to 1562°F (850°C) in air
CLICK HERE TO SEND INQUIRY OR REQUEST A QUOTE
Categories: , Tags: ,
CLICK HERE TO CHAT WITH AN EXPERT ABOUT THIS PRODUCT

Boron Nitride Coatings | ReleaSys™ HTX-WBN

Superior Release and Lubricity; Water-based ; High-Temperature Release Agent (600-1800°F)

ReleaSys™ HTX-WBN is a specialized, water-based boron nitride coatings agent specifically designed for high temperature molding operations.  This formula utilizes a proprietary boron nitride complex to achieve unmatched lubricity and mold release performance. ReleaSys™ HTX-WBN boron nitride coatings prevent sticking and galling to increase life of dies/molds, improve product surface finishes, and reduce production times. ReleaSys HTX-WBN makes an excellent surface coating for molds used to produce castings of light metals such as magnesium and for coating surfaces in glass making operations. Thanks to proprietary slip additive, the boron nitride coating is also be used as a high performance release coating for continuous process and high temperature plastics. Our formulation is 100% VOC-free making it an eco-friendly and safer alternative to solvent-based alternatives. Applications include:

  • Mold Release for High Temperature and Difficult to Mold Polymers and Composites
  • Mold release for Casting Metals and Glass
  • Mold Dressing for Powder Metal Processing
  • Surface Coating for High Temperature Surface
  • Barrier Coating for Aggressive Environmental processes
  • Specialty Lubricant for Drawing and Working Metals

Designed to provide unmatched dry lubrication and barrier properties, the ReleaSys™ HTX-WBN imparts surfaces with a low coefficient of friction and ultra durable coating that is non-wetting and inert, protecting mold and die surfaces while enhancing productivity and part quality. The coating offers exceptional release properties, even at 600-700 °C, and superior protection from aggressive environments. ReleaSys™ HTX-WBN can inhibit corrosion and chemical attack in metal forming, glass-making and sintering processes, thereby increasing die life and improving product quality.

ReleaSys™ HTX-WBN Boron Nitride Coatings – Superior Chemistry, Superior Results

Boron nitride coatings developed by proper application of ReleaSys™ HTX-WBN are extremely durable and stable, allowing for longer operational time before re-application is necessary.  Miller-Stephenson’s proprietary boron nitride complex technology allows for greater surface adhesion, lubricity, and stability meaning operators can mold more parts without the need for constant re-application.  Moreover our boron nitride coatings exhibit minimal mold fouling and transfer, allowing expensive molds to remain in service longer with the need for expensive re-surfacing to occur. Our boron nitride coating within ReleaSys HTX-WBN can inhibit corrosion and chemical attack in metal forming, glass-making and sintering processes, thereby increasing die life and improving product quality. For an equivalent aerosol alternative our ReleaSys HTX-A is a valuable and effective coating that should be equally considered

For help with choosing which mold release is right for your application check out article section here

For further reading regarding our ReleaSys product line and Applications – our most helpful article for selecting the best product for your needs

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

Physical Properties:

Primary Polymer:……Discrete Ceramic particle complex

Appearance:…………White particle suspension

Odor:………………….None

Specific Gravity:…….1.0 g/mL @ 25°C

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

ReleaSys HT

High Temperature Mold Release

Download File

 Recommended Application Procedure

  1. Clean surface thoroughly. Mechanical cleaning such as bead media blasting or steel wool, followed by chemical cleaning, provides the best surface for application of Boron Nitride. Removal of all previous contaminates is critical.
  2. Lightly swirl ReleaSys™ HT, making sure to re-disperse all particles prior and during use. Mold temperature would ideally be above 180 °F prior to application. Apply approximately 8-10 inches away from surface, and apply a light coat. NOTE: Material will apply wet and transparent, but will dry to a fine-white coat.
  3. Allow to dry completely. Heat mold to operational temperatures (>500° C) to allow boron nitride to adhere to surface. Apply 1-3 coats and repeat heat cycle to maximize release performance.  If using as a dry lubricant or barrier, allow to dry and then apply 1 additional coat to guarantee uniform coverage.

The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.

Quart, Gallons, 5 Gallons, 55 Gallon Drums, 275 Gallon totes
