Krytox™ VPF 1525 Oil
Krytox™ VPF 1525 oil is chemically inert, non-reactive to all elastomers, plastics, metals and has a Viscosity of 250 cSt at 20°C.
Krytox™ VPF 1525 Oil | For High Vacuum Applications
NSF H-1 Certified For Incidental Food Contact
Krytox VPF 1525 vacuum pump fluids are used in applications where conventional vacuum pump oils cause safety, waste disposal, and maintenance problems. They are nonflammable and eliminate the chance of fire in pumps. They are nonreactive and safe to use in oxygen systems. They can replace competitive PFPE fluids as well as any other type of vacuum fluid. Krytox™ fluids do not contain acetal groups, which are susceptible to attack by Lewis acids. This gives Krytox™ superior stability as a vacuum pump fluid. Krytox vacuum fluids are precisely distilled to provide low vapor pressures and superior performance. In addition, Krytox fluids are recyclable.
Why Krytox VPF 1525 Oil?
While Krytox VPF fluids are inert and non-reactive to all elastomers, plastics, and metals, the soluble additives in Krytox™ XP products have not been tested with all materials. Initial testing has shown no problems with Teflon™ fluoroplastic resin, Kalrez® perfluoroelastomer parts, Viton™ fluoroelastomer, nitrile, and silicone rubbers. The performance of the soluble additives could degrade at temperatures more than 182 °C (360 °F) over a long period of time. For applications that require Extreme Pressure Oil, see Krytox™ XP Series.
Miller-Stephenson: Lubrication Experts, Superior Chemistry, Fast Delivery – a potent combination
At Miller-Stephenson, we understand the challenges engineers and scientists face with trying to select the best lubricant for current or new applications. With over 60 years of real-world experience, our highly trained team of technical experts and field engineers can assist you with identifying and selecting the optimal lubricant that best fits your operational parameter. Our large inventory of high-performance PFPE-base Krytox™ lubricants from Chemours, ensures we have the right lubricant for your needs, regardless of temperature, environment, safety, or performance of your system demands. For further information please review the articles below or contact a Miller-Stephenson representative.
Krytox™ is a trademark of The Chemours Company FC, LLC.
For more benefits and related articles:
To learn more about Krytox NSF H-1 Rated Food Grade Lubricants click here.
To learn more about Krytox Automotive Solutions click here.
To learn more about Krytox Automotive Noise, Harshness and Vibration solutions click here.
For the Krytox Frequently asked questions (FAQ) click here.
For a general Krytox application overview, click here.
With help regarding which Krytox grease is right for you, click here.
The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.
| VPF Properties | |||||
| 1506 | 1514 | 1525 | 1531 | 16256 | |
| Kinematic Viscosity (cSt) | |||||
| @20°C | 60 | 140 | 250 | 310 | 2560 |
| @100°C | 4.1 | 7.2 | 10.6 | 12.5 | 64.6 |
| Density (g/cc) | |||||
| @20°C | 1.88 | 1.89 | 1.9 | 1.9 | 1.92 |
| @100°C | 1.73 | 1.74 | 1.75 | 1.75 | 1.78 |
| Pour Point °C (°F) | -60(-76) | -54(-76) | -48(-54) | -41(-42) | -15(5) |
| Food Contact Approval | NSF H-1 | NSF H-1 | NSF H-1 | No | No |
The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.
VPF TDS
Technical Data Sheet
- Vacuum Pumps
- Semi-Conductors
The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.
| Syringe | Dab-O-Matic | Needle Nose Bottle | Jar | Bottle | Jug |
.5 oz. | 1 oz. | 1 oz. | .5 kg | 1 kg | 5 kg |
| 1 oz. | 2 oz. | 2 oz. | 20 kg | ||
2 oz. | 4 oz. | 4 oz. | |||
4 oz. |
The recommendation made here with and the information set forth with respect to the performance or use of our products are believed, but not warranted to be accurate. The products discussed are sold without warranty, as to fitness or performance, express or implied and upon condition that purchasers shall make their own test to determine suitability of such products for their particular purposes. Likewise, statements concerning the possible uses of our products are not intended as recommendations to use our products in the infringement of any patent.
- NSF H-1 Rated
- ASTM D445
- ASTM D97
- ASTM D1160
- ASTM D2595
