Flux Remover Spray | H0805A/H0B05B

H0805A/H0B05B | Flux Remover Spray

Strong, Nonflammable, Aerosolized Flux Remover, Replaces nPB and HCFC-225 In Many Applications

A strong nonflammable flux remover spray containing a blend of hydrofluoroethers with trans-1, 2 dichloroethylene and isopropyl alcohol. This mixture is a blend of azeotropes and is ideally suited for removal of rosin, organic flux, oils, grease and waxes. Can also be used for precision and specialty cleaning. Evaporates quickly and leaves no residue. It replaces nPB and HCFC-225 in many applications.

Advantages of Miller-Stephenson Flux Remover Spray

• Evaporates quickly
• Leaves no residue
• Nonflammable
• Non ozone depleting
• RoHS Compliant

Properties of Solvent

Boiling Point……………………………………………..113°F/45°C

Vapor Pressure………………………………………….360 mm Hg

Liquid Density………………………….1.27 g/ml @ 70°F/21°C

Ozone Depletion…………………………………………………..0.00

Global Warming Potential, H0805A……………………….35.6

H0805B……………………….43.0

Plastic Compatibility

(Immersion: 15 minutes at Room Temperature)

• Acetal
• Polyethylene
• Polypropylene
• Liquid Crystal Polymer
• Polyester, PBT, PET
• Epoxy
• Polysulfone, PSO
• PEK, PEEK
• Polyimides
• PTFE
• Phenolic
• Polyvinylchloride

NOTE: Acrylic, ABS, and polycarbonate, if under stress, may show slight cracking or crazing damage. Test for compatibility before use.

Flux Remover Spray Elastomer Compatibility

(Immersion: 15 mins at Room Temperature)

• Butyl Rubber*
• Natural Rubber
• Polysulfide
• EPDM
• Buna S*
• Buna N
• Neoprene*
• Urethane
• Chlorosuflonated PE
• Silicone
• Fluoroelastomers

Elastomer swelling and shrinking will, in most cases, revert to within a few percent of original size after air drying. Swell, shrinkage, and extractables are strongly affected by the compounding agents, plasticizers, and curing used in the manufacture of the elastomers. Test for compatibility before use.

Metal Compatibility

(Immersion: 2 weeks at 248°F/120°C)

• Aluminum
• Copper
• Iron

Note: Test for compatibility before use.
